BitLogic Documentation¶

BitLogic is a modular PyTorch library for differentiable Look-Up Table (LUT) neural networks, built for research and for efficient FPGA deployment.

2026 rewrite — design inspired by torchlogix

BitLogic was rewritten from the ground up to follow the design philosophy of torchlogix by Lino Gerlach et al. — a minimal, torch.nn-native API composed with nn.Sequential. The GroupSum head, the binarization-as-module encoder pattern, and the train/eval mode-switching discipline all come directly from torchlogix. Our warp parametrization implements Gerlach's own WARP-LUTs paper. Full credit is in the README Acknowledgments.

BitLogic Architecture

What's in the box¶

BitLogic is intentionally small. The public API is a torch.nn-native stack of three things:

Encoders — turn continuous data into bits. Two implementations: Thermometer and DistributiveThermometer.
Layers — one class, LogicDense, composed of a parametrization (what the LUT is) and connections (which inputs feed each neuron).
Heads — reduce layer outputs to task-specific shapes. GroupSum is the default popcount head; GroupedDSP adds a tanh-bounded learnable k×k weight matrix with signed integer quantization at eval time.

Under the hood, LogicDense forwards by gathering lut_rank inputs per neuron via its connection module, then contracting them through the chosen parametrization. The whole model is a plain torch.nn.Sequential.

A ten-line network¶

import torch
from bitlogic import DistributiveThermometer, LogicDense, GroupSum

enc = DistributiveThermometer(num_bits=8).fit(train_samples)   # (N, 1, 28, 28)

model = torch.nn.Sequential(
    enc,
    torch.nn.Flatten(),
    LogicDense(6272, 64000,
               parametrization="light", lut_rank=4,
               connections="learnable", num_candidates=8),
    LogicDense(64000, 64000,
               parametrization="light", lut_rank=4,
               connections="learnable", num_candidates=8),
    GroupSum(k=10, tau=150),
)

See Quick Start for a complete end-to-end MNIST example.

Choosing a parametrization¶

Parametrizations are picked by name ("light", "warp", "linear", "polylut", "neurallut", "dwn", "difflogic"). Each implements a different inductive bias over the truth table:

Name	What it is	Supports `lut_rank`	Notes
`light`	Kronecker-indicator basis	2, 4, 6	Good default. Soft / hard / Gumbel sampling.
`warp`	Walsh–Hadamard basis	2, 4, 6	Fast, smooth.
`linear`	Affine + sigmoid	any ≥ 2	Simplest baseline.
`polylut`	Monomial basis (degree D)	any ≥ 2	Structured pruning style.
`neurallut`	Tiny MLP per neuron	any ≥ 2	No residual init.
`dwn`	Binarized input + EFD gradient	2, 4, 6	Direct LUT lookup.
`difflogic`	Softmax over 16 Boolean ops	2 only	Differentiable logic gates.

Full reference: Parametrizations.

Choosing a connection pattern¶

Kind	Trainable?	Typical use
`fixed`	no	Sparse, random routing (the LogicNets / DLGN default).
`learnable`	yes	Per-slot candidate pool with softmax + straight-through argmax. Set `num_candidates=-1` to open it up to every input (dense; expensive, exact).

Full reference: Connections.

Getting started¶

Installation — set up BitLogic with uv.
Quick Start — build and train a LUT network on MNIST.
Examples — runnable MNIST quickstart that matches the Quick Start guide.

Guides¶

Contributing — dev loop, branching, versioning, CI.
Examples — the runnable MNIST quickstart.
HDL Export — SystemVerilog emit + Yosys NAND2-GE flow.

API Reference¶

Overview
Layers — LogicDense
Parametrizations — LUT shapes
Connections — input routing
Encoders — thermometer-style bit encoders
Heads — GroupSum, GroupedDSP
